Electrical parameters:
Sensitivity: 3.94mV/mm/s (100mV/in/s) ± 5%.
Frequency response: 4.5Hz to 5kHz (270cpm to 300kcpm) ± 3.0dB; 6.0Hz to 2.5kHz (360cpm to 150kcpm) ± 0.9dB.
Speed range: 1270mm/s (50 in/s) peak.
Lateral sensitivity: less than 5% of sensitivity.
Amplitude linearity: ± 2% to 152mm/s (6in/s) peak.
Installation resonance frequency: greater than 12kHz.
Lower limit of broadband noise: 0.004mm/s (160 μ in/s) rms (nominal value).
Output bias voltage: -12 ± 3.0Vdc, relative to pin A.
Dynamic output impedance: less than 2400 Ω.
Environmental parameters:
Working temperature range: -55 ° C to 121 ° C (-67 ° F to 250 ° F).
Impact resistance: Maximum peak weight of 5000g.
Relative humidity: 100% non immersed in water, with a sealed shell.
Mechanical parameters:
Weight: Typical value is 142 grams (5.0 oz).
Diameter: 25.3mm (0.995in).
Height: 63.2mm (2.49in).
Shell material: 316L stainless steel.
Connector: 2-pin Mil-C-5015, sealed, 316L stainless steel casing.
Installation torque: maximum 32-46kg · cm (24-40in lb).
Polarity: When the sensor housing moves towards the connector, pin A is positive relative to pin B.
Output characteristics:
Surge current: Provides 3A current for 10ms without tripping.
Output voltage drop: maximum 0.3Vdc.
Steady state overcurrent trip: typical value of 5A per point.
Output leakage current: maximum 0.1mA.
Open response time: maximum 0.5ms.
Closing response time: maximum 0.5ms.
Protection function: It has short-circuit protection, overcurrent protection, and overheating protection, all of which automatically recover.
In addition, the installation thread of this model of sensor is M8 × 1, which has multiple certifications such as CSA and ATEX.
