Input Signal: Receives a non-contact signal from the 3300 Series 5mm, 3300 8mm, or 3300 XL 8mm proximity probe and extension cable.
Power requirements: -17.5Vdc to -26Vdc without barrier, 12mA; -23Vdc to -26Vdc is required when there is a safety barrier. The supply voltage sensitivity is less than 2mV for every 1 volt change in the input supply voltage.
Extension cable capacitance: 69.9 pF/m (21.3 pF/ft) typical.
Field Connection: Conductor sizes are 0.2 to 1.5 mm² (16 to 24AWG), 0.25 to 0.75 mm² (18 to 23AWG) with metal rings. The length from the 3300 XL front extender to the monitor is 305 m (1000 ft).
Linear range: 2mm (80mils), linear range starts from about 0.25mm (10mils) from the target surface to correspond to voltages from 0.25 to 2.3mm (10 to 90mils) about - 1 to - 17Vdc.
Recommended clearance setting: 1.27mm (50mils).
Increasing Sensitivity (ISF): 7.87 V/mm (200 mV/mil) ±5 percent including interchangeability error when measured in 0.25 mm (10 mils) increments over a linear range of 0°C to 45°C (32°F to 113°F) over an 80 mil linear range of 0 °C to 45 °C (32 °F to 113 °F) for a standard 5m system; The standard 9m system is 7.87V/mm (200mV/mil) ±6.5%.
Temperature performance: Less than ±0.025mm (±1mil) at 0°C to 45°C for standard 5m system components and less than ±0.038mm (±1.5mil) from 0°C to 45°C for standard 9m system components.
Frequency response: 0 to 10kHz, 0 to -3dB typical (305 m field line).
Small face size: 15.2mm (0.6inch) diameter (flat target).
Shaft Diameter Requirements: Small shaft diameter is 50.8mm (2in), small shaft diameter is 76.2mm (3in) recommended.
Probe temperature range: -51°C to 177°C (-60°F to 351°F) for standard probes; The wide temperature range is -51°C to 177°C at the end of the probe and -51°C to 260°C (-60°F to 500°F) for probe cables and connectors.
Tensile strength: 330N (75 lb) from probe housing to probe head, 270N (60 lb) from probe head to extension cable gland
