The Bentley 330103-00-10-05-02-00 is a 3300 XL Series 8mm Proximity Current Sensor Vibration Probe, the parameters of which are as follows:
Probe Type: Part of the 3300 XL series 8mm eddy current transducer for non-contact measurement of vibration, displacement, and other parameters of rotating machinery shafts.
Unthreaded length: "00" means that the unthreaded length is 0mm.
Total length of case: "10" means the overall length of the case is 100mm.
Overall length: "05" indicates that the total length of the probe is 0.5 m (1.6 ft).
Connector & Cable Type: "02" refers to the use of miniature coaxial Click Loc™ connectors, standard cables.
Agency approval options: "00" indicates that there is no special agency approval, and if it is "CN", it means approval such as explosion-proof certification for a specific country (China), which is generally used in places with explosion-proof requirements such as chemical plants or oil refineries.
In addition, other features of the probe include:
Measuring principle: Vibration and static displacement are measured by the change in the gap between the probe end and the object to be measured.
Linear range: 2mm.
Sensitivity: 7.87V/mm (200mV/mil) ±5%.
Frequency response: 0 - 10kHz.
Operating temperature range: -35°C to 85°C.
Probe tip material: polyphenylene sulfide (PPS).
Probe case material: AISI 303 or 304 stainless steel (SST).
This type of probe can be used for on-line vibration monitoring and protection of various rotating machinery such as steam turbines, fans, compressors, pumps, motors and generators, which can provide powerful analysis methods for equipment fault detection and reliable protection for equipment
