Input: Receives a non-contact 3300 HTPS 16mm proximity probe and extension cable.
Power supply: Requires - 19.6Vdc to - 26Vdc, current max 12mA. When operating at voltages higher than -23.5Vdc, this will result in a decrease in the linear range.
Supply Voltage Sensitivity: The output voltage changes by less than 13mV for every 1 volt change in the input supply voltage.
Output impedance: 50Ω.
Extension cable capacitance: 69.9 pF/m (21.3 pF/ft) typical.
Field line: The maximum length from the 3300 HTPS preamplifier to the monitor is 305 m (1000 ft).
Linear range: 4.0 mm (160 mils), linear range from approximately 0.5 mm (20 mils) from the target surface to 0.5 to 4.5 mm (20 to 180 mils) (approx. -2 to -18Vdc).
Recommended clearance setting: 2.5mm (100mil).
Increasing Sensitivity (ISF): The ISF includes a commutability error of 3.94V/mm (100mV/mil) ±9.65% when measured in 0.5mm (20mil) increments over a linear range of 4.0mm (160mil).
Linearity Deviation (DSL): Less than ±78μm (±3.1mil).
Temperature Range Performance: ISF is maintained at 30% ± 30% at 3.94V/mm (100mV/mil) and within ±0.51mm (±20mils) when the probe temperature range is 22°C to 350°C (72°F to 662°F).
Frequency response: 0 to 6kHz, 0 to -3dB typical, 305 m (1000 ft) field line.
Recommended minimum target size: 30.5 mm (1.2 inch) diameter (flat target).
Recommended minimum shaft diameter: 152mm (6.0inch).
